Model No. |
DS-U-25 |
DS-U-40 |
DS-U-60 |
DS-U-100 |
|---|---|---|---|---|
| Max Drilling Dia | 25 mm | 40 mm | 60 mm | 100 mm |
| Number of Spindle | 2 | 2 | 2 | 1 |
| Distance Between Spindle Bed | 150 | 160 | 160 | 180 |
| Max Spindle Speed | 3600 | 3200 | 3200 | 800 |
| Spindle Bor | 40 mm | 50 mm | 50 mm | 60 mm |
| Each Spindle Power | 5 HP | 7.5 HP | 15 HP | 20 HP |
| Ball Screw Dia | 32X10 | 40X10 | 40X10 | 40X10 |
| LM Guide way | 35 mm | 45 mm | 45 mm | 55 mm |
| Servo Motor | 1KW | 1.5 KW | 2 KW | 1.5 KW |
| ZAXIS Travel | 350 mm | 400 mm | 400 mm | 450 mm |
| ZAXIS Travease Rate | 3600 mm per minute | 2400 mm per minute | 2400 mm per minute | 2000 mm per minute |
| Bed Size | 350X450 | 500X 600 | 500X 600 | 500X 650 |
| Coolent Size | 1.5 KW 1NoS | 1.5 KW 1NoS | 1.5 KW 2NoS | 1.5 KW 1NoS |
| Working Table Height | 36" | 36" | 36" | 36" |
| Overall Dimension | 2000X1700X2000 | 2300X1700X1900 | 2400X1700X1900 | 2600X1700X2000 |
| Total Machine Power | 17 HP | 23 HP | 38 HP | 26 HP |
| Machine Weight (approx) | 1100 KG | 1500 KG | 2000 KG | 2000 KG |
